Motherboard chip |
Intel Q270 |
|
CPU |
Intel 6th/7th/8th/9th Generation CPU |
|
|
Optional: I3-8100, I5-9400, I7-9700, etc. |
|
memory |
2*DDR4 DIMM, 2666MHz/ maximum memory support 32G. |
|
Cunzhu |
1* M.2 slot (NVME/NGFF protocol); 3*SATA 3.0 6Gb/s interface |
|
Display interface |
1*HDMI1.4 interface, 1*VGA interface |
|
network |
1*RJ45 interface /1*WIFI interface |
|
Network card chip |
Realtek gigabit network card chip |
|
PCIE slot |
1*PCIE 3.0 X16 slot; 1*PCIE X1 slot |
|
audio frequency |
1*Line out； 1*Mic In； 1*Line In； 1*F_Audio built-in pin |
|
Audio chip |
Realtek HD audio chip |
|
serial port |
/ |
|
PS/2 interface |
/ |
|
Usb interface |
Rear interface: 2 * USB 3.0; 4*USB2.0 Built-in pins: 1 set of USB2.0 pins (2 USB2.0 ports can be extended); 1 set of USB3.0 pins (2 USB3.0 ports can be expanded); |
|
Functional pin |
1*FPANEL panel pin; 1*4Pin buzzer pin; 1*4Pin CPU fan; 1*3Pin SYS fan; 1*TPM pin |
|
Power input |
24Pin+8Pin ATX power socket |
|
product size |
170 x 190mm x 4L; |
|
Working temperature |
-10℃~60℃ |
|
Working humidity requirements |
10%~90% without condensation |
|
Storage temperature |
-25℃~70℃ |
|
power consumption |
Standby power consumption: 20~45W Full load power consumption: 70~200W (for reference only) |
|
other |
1*JBAT |
